There will be a revision 2 of this model with a better cable channel in the arm and a built-in LED socket. The electronic diagram is on its way. Stay tuned!

Small and simple LED moving head light. Design to hold discrete LED in the light and there is a guide whole to bring the cabling to the base.
Some basic gobos are included for added effect and a blank gobo is also available for you to customize. You can then shine any logo anywhere since it is battery powered.

There is sufficient space for electronic circuitry if anyone feels adventurous.

You can now see the result of my prints. I might do some tweaking here and there to improve print quality. (Like the arm could be printed lying instead of standing).

There is now a more realistic moving head wich includes servo motors. http://www.thingiverse.com/thing:1912706

Enjoy this Thing and share the result of your prints.

Build of material

1 x All printed part 1 x Your selected gobo 1 x LED (or any other light source that fits) 1 x power source (either battery or external power)

Here is guide instruction to help you assemble the fixture.

1. Print all part and prepare all electronics
2. Glue LED to the light plug. Then glue the plug to the light.
3. Assemble the light fixture using #4-40 screws and nuts.
4. Pass the wiring in the guide whole
5. Add battery to the base of the light

(Optional) Drill a whole to add a switch.

Note: You might need to orients the part for printing.
