Cradle for the Sharpstar 50EDPH scope. There is six versions :

• One version using the Synta style dovetail.
• One version using the Losmandy style dovetail.
• One version using the Vixen style dovetail.
• One version using the Losmandy D Clamp style with two threaded 1/4-20 holes (using nylon screws will prevent denting your dovetail).
• One version using the Vixen Clamp style with two threaded 1/4-20 holes (using nylon screws will prevent denting your dovetail).
• One version for universal application with two holes for 1/4-20 screws with socket head cap. **This version will need a shim block beneath the cradle otherwise the scope/focuser will make contact with the dovetail. I decided to leave the shim block separate on the STL file so you can adjust the height for you setup. There is also the two negative parts for the 1/4-20 bolts in the STL file so your custom shim block can match the holes on the cradle.

Each version has two models, one straight and one with a recess to compensate for the red locking screw on top of the scope, giving you more room for your fingers.

You'll need four M4 X 12 (or16) bolts depending if you use felt liner or velcro and four M4 X 10 inserts. I did my test using ASA but printing with PA-CF would be stronger.

Save weight by modifying the infill density depending on the area (see picture - approx 82 grams). If the weight isn't an issue, you can print it at the infill density you want.

**Some felt liner (or velcro) is needed to make sure the scope is secured into the cradle othewise the scope could still be rotated into the cradle once bolted.
