I created this case using TinkerCAD (my first 3D thing design). Echenelly's mount is for the uLCD-32PTU display module. This case is for the originally specified uLCD-32PT display module. The mounting hole arrangement is significantly different between the two.

A cutout is provided for easy access to the display's uSD Card.

I'm currently using this display module along with a modified version of Marlin RC2 running on a Sanguinololu 1.3a.

Marco's original design is avaialble here: http://www.thingiverse.com/thing:38749

You will need 4) M3x10mm screws and nuts for mounting the display to the case. For mounting the case to the MendelMax, you can simply reuse the 4) M5x10mm screws from the replaced vertex.
