Descrição
"Big Motorized Roller Blind - Prototypes" - Tasmota The learning process before I made the final version 04. Instructions will be at "Big Motorized Roller Blind" - https://www.thingiverse.com/thing:5575324
The goal was to lift a big and heavy roller blind fast and silent using Apple HomeKit. I managed to do that but it took some time before I was satisfied.
Roller blind:
Width: 200cm Length: 190:cm Tube: ID:24 -+1mm Weight: 1,8kg Type of operation: bead chain
Sadly Jysk don't sell the roller blind anymore. It looks like this: https://jysk.co.uk/curtains/blinds/roller-blinds/blackout/blackout-blind-bolga-180x170cm-white
Version 04 and final:
Nema17, timing belt, bearing wheel and spur gear
Go to the final version - "Big Smart Motorized Roller Blind" - https://www.thingiverse.com/thing:5575324
Version 03:
Nema17 and three spur wheels Gearing: 2,6:1 (spur gear (10-12-26 teeth)) Perfect gear ratio but still too noisy at high speed.
Version 02:
Nema17 and two spur wheels Gearing: 1:1 (spur gear (26 teeth)) I used the locking mechanism from the original roller blind. Noisy and sometimes the nema17 couldn't lift the blind due to the gear ratio.
Version 01:
Nema17 Planetary Gearbox 5,18:1 Didn't work. The roller blind was too heavy to hold its position and too slow.
