Modelo 3D Socket Driver Attachments por andrewpearce no Thingiverse

Descrição

These are useless on their own.

To be used as attachments for custom ratchet spanner tools, insert object and attach to your design.

How to insert (Fusion 360):

  • Insert/Insert Mesh, choose file
  • Mesh/Prepare/Generate Face Groups, select inserted mesh, click OK
  • Mesh/Modify/Convert Mesh, select inserted mesh, select "Prismatic", click OK
  • Move converted mesh into position with Modify/Align
  • Modify/Combine to join bodies

Make sure to fillet at attachment point for strength.

Sizes included - 1", 3/4", 1/2", 3/8", 1/4"

*image is of a custom tool using the 3/8 file

Thingiverse

Socket Driver Attachments

0
Curtidas
0
Downloads
1
Coleções
Tags
attachment driver ratchet socket socket wrench wrench
Licença Creative Commons - Attribution - Share Alike
Arquivos (5)
4ths_Inch_Socket_Attachment.stl 112.1 KB
8ths_Inch_Socket_Attachment.stl 112.1 KB
Half_Inch_Socket_Attachment.stl 112.1 KB
4ths_Inch_Socket_Attachment.stl 112.1 KB
1_Inch_Socket_Attachment.stl 112.1 KB
