A eurorack mounted Xprotolab oscilloscope module panel.

You'll need to somehow obtain a discontinued Xprotolab module from Gabotronics.com to build one. You'll also need some strip board, a 5v regulator, two capacitors for the regulator, an LED, a 220ohm resistor for the LED coming off the 5V regulator (to indicate the module 5v output is working properly), four Thonkiconn mono 3.5mm audio jacks and a vertical PCB mounted potentiometer (like alpha(s)) to use for an attenuator to hook up to channel 2 input, just for fun. The outputs are simply "multed" inputs to pass through the signal to other modules in the signal chain. I threw in a D shaft knob file. Print this with TPU so it slip fits the D shaft potentiometers. The panel can be printed with PLA. It's flimsy at first, until the whole module is assembled and soldered/screwed together, but solid when completed.

The panel is one hair wider than a normal 8HP panel but if you scoot your other panels to the left and right, it should still fit a normal 8HP slot. This tiny extra width is to accommodate the Xprotolab PCB.

Notice: I do not make, own, claim fame to or take any credit for the Xprotolab mini oscilloscope designs or products. You can find those at gabotronics.com and I believe they are mostly discontinued. All I did here was make one into a Eurorack mounted module for easier use for what I use it for.
