The KMS VertiBus combines a Alien style body with a vertical frame design known from the Infinitum and Singularitum frames from blitzfpv.

Key features: ==================== 5" Prop Size Vertical Box Style Frame 30.5x30.5 M3 Stack Size (1 Mounting position in the center) 20x20 M2 Stack Size (4 Mounting places, 1 shared with 30.5x30.5, 1 on top plate) 16x16 M3 Motor Mount

Required Hardware: ====================

• 8 x 30mm standoffs
• 16 x M3x8 button head screws
• 16 x M3x16 socket head screw

Required Carbon Parts: ==================== This should not be 3D printed, they need to be cut from 1.5mm and 2mm CFK The CFK Parts are containing a lot of slots that needs to match the CFK thickness of the 2mm CFK Parts. The fitting needs to be tight and they are therefore designed with 0 tolerance. Depending on the CFK you can get anything from 1.9mm to 2.1mm when ordering 2mm CFK. Therefore the two additional zip files contain files adapted to match 1.9mm and 2.1mm. I strongly Recommend to do a few test cuttings with the motor mounts and bottom plate to ensure a tight fit. All dog bone style corners are designed to fit a 1.5mm cutter.

1.5mm CFK:

• 2 x Cam-Plate.dxf
• 1 x Top-Plate-Type-1 or Top-Plate-Type-2

2.0mm CFK:

• 2 x Arm_type-1
• 2 x Arm_type-2
• 1 x Bottom-Plate
• 2 x Brace-Front-Back
• 2 x Brace-Side
• 8 x Motor-Mount

A short demo video: https://youtu.be/Ja7eXmKkDbM

If this is your first vertical frame, have a look at my build instructions: https://youtu.be/j2TxkOUZpQ0
