Modelo 3D LED Strip mounting brackets por Snobound2 no Thingiverse

Descrição

I made these specifically for my "Light up your drawers" project - https://www.thingiverse.com/thing:3610409 - where I feature a Hall Effect magnetic switch to control the LED Strip .

I remixed tiziojoe's LED Strip Clip to fit different size LED Strips and created some extended and interlocking pieces for full length, no sag fastening.

Most common LED Strips come in 8 mm and 10 mm widths, flat strip or waterproof, so I made pieces to accommodate these formats. The pieces are approximately 100 mm and 200 mm in length so they easily fit on most printer beds and can be printed in multiples. They interlock so you can chain them together to any length you want and attach with #4 wood screws.

No need to "thread" the LED Strip in, just place one edge in a groove and snap it into place.

Thingiverse

LED Strip mounting brackets

248
Curtidas
0
Downloads
449
Coleções
1
Impressões
Tags
LED Led Holder led mount led strip
Licença Creative Commons - Attribution
Arquivos (12)
10mmLED_Strip100Middle.stl 164.1 KB
10mmLED_Strip100M.stl 132.9 KB
10mmLED_Strip100F.stl 112.9 KB
10mmLED_Strip200Middle.stl 240.9 KB
8mmLED_Strip100Middle.stl 197.5 KB
8mmLED_Strip100M.stl 141.8 KB
8mmLED_Strip100F.stl 120.1 KB
8mmLED_Strip200Middle.stl 233.5 KB
Flat8mmLED_Strip100F.stl 30.3 KB
Flat8mmLED_Strip100Middle.stl 42 KB
Flat8mmLED_Strip100M.stl 56.7 KB
Flat8mmLED_Strip200Middle.stl 70.8 KB
