This is an enclosure for the Makerbot Replicator +, make with the aim to print more complicated filament type than PLA, and expand your Replicator+ possibilities.

Attached you will find the parametric drawing in STL forma, so you will be able to modify if requires. DESIGN PARTS:

*Hinges: made in several parts, but I guess can be made in a single print instated to ensamble screwed. *Latch: single print mechanism: print it angled with little support.

All the parts are designed to be ephemeral; only glued with double adhesive tape, to preserve the machine structure.

EXTRA MATERIAL:

*You will need 3 metrachilate plates, with following dimensions: 1x- L: 46cm W: 32cm (with two holes of 12mm: at 6cm from the top, and 6cm from the right /left borders respectively) 2x- L: 31.5cm W: 32cm (with two holes of 12mm: at 6cm from the top, and 6cm from the right /left borders respectively)

*double adhesive tape, 0.3 to 0.4 of thickness.

This design that requires a little sanding and adjusting.

I encourage all you to remake it and think about to enclose the top. Enjoy!!
