Hexeract

Open-source Core-XY motion platform mainly for "large" print volume desktop 3D printer hexeract__Motion_ _Extrusion Platform v81

Introduction

The Hexeract is an open-source Core-XY motion platform with a rigid main chassis using 3030 aluminum extrusions and moving components constructed by 1515 aluminum extrusions.

The design is a motion platform, components like; motherboard, LED lights, HEPA filters, and more are for the individual builder to determine. Also, the "Hexeract calculator" will output the length of components to accommodate various size requirements.

DISCLAIMER: Not for the faint of heart

The cost of building will probably be higher than you think
The allowable tolerance of the printed parts are tight

The rate of development and updates will be uncertain until the first quarter of 2022 (refer to the announcement in the Discord server)

This project is in development
The current "Bill of Materials" and "Assembly Guide" are barebones
The "Calculator" is incomplete

Community: Discord

The announcement will explain a lot of the incompleteness of this project
Designer will be there on the weekends answering questions

Recomended Print Settings for 3D Printed Parts

Filament Material: PETG, ABS, ASA
Layer Hight: 0.2mm
Extrusion Width: 0.4mm
Infill Percentage: 20%
Infill Pattern: "Tri-Haxagon"[Cura] / "Star"[PrusaSlicer]
Supports: NO
Ironing Pattern: Zig Zag[Cura]
Brim Line (Count / Width): 15 Lines / 6mm
Print Wall (Count / Thickness): 4 Lines / 1.6mm
Top & Bottom Layer (Count / Thickness): 8 Layers / 1.6mm

Hexeract Calculator (In Working Progress)

If one wants to have a different print volume

Recommended X-axis "Print Volume" : 250mm ≤ (x-axis "Print Volume") ≤ 450mm
Significant modification will be necessary to the Z-axis if one wants to go with a larger print volume than standard.

How to use the calculator (In Working Progress):

[](http://www.youtube.com/watch?v=7c40CwL1CL%M% "How to Use the Calculator")

CAD File Link

Bill of Material Recommendations

*not a comprehensive list of materials but a list of recommendations

Bolts: the M3 Socket head bolt length and quantity update will be uncertain until the first quarter of 2022

Size	Length	Type	Quantity
M8	15mm	Black Oxide Steel Finish / Button Head	8
M8	25mm	Black Oxide Steel Finish / Button Head	16
M8	45mm	Black Oxide Steel Finish / Socket Head	4
M6	15mm	Button Head	62
M5	45mm	Hex Head	2
M3	"n"mm	Socket Head	"n"
M2	12mm	Socket Head	4

Nuts

Size	Type	Quantity
M6	for 30x30mm Extrusions	62
M3	for 30x30mm Extrusions	(total # of mounting holes in the MGN12H rails for the 30x30mm Extrusion)
M3	for 15x15mm Extrusion	(Packet of more than 50 recommended)
M3	Standard Hex	2
M3	Standard Hex	(Packet of more than 50 recommended)
M3	Length: ≥7mm / Hex	4
M2	Standard Hex	4

Washers

Size	Type	Quantity
M3	Stainless Steel / Standard size	20(Recommended)

Electrical Components: If given the chioce, 24v is hightly recommended

Components	Recommended Product	Spcifications	Quantity
Hotend	E3D V6	1.75mm / Direct Drive	1
Endstop	Omron SS-01-E	---	2
Z-probe	BL touch v3	---	1
Part cooling fan	---	5015 Blower fan	1
Stepper Motor (XY Axis)	---	NEMA 17	2
Stepper Motor (Extruder)	(the motor will come with the Orbiter v1.5)	---	1
Stepper Motor (Z-Axis)	E3D LEADSCREW MOTOR WITH POM NUT (dos do not have to be this one. ONLY for CAD file specification build)	NEMA 17 / Body Length: < 30mm / Integrated Lead Screw Length: (in the calculator)	2
Print Bed	E3D High-Temperature Heated Bed	---	1

Notes on Wiring

DISCLAIMER: Recommendations from a nonexpert in electronics. These recommendations will not be responsible if accidents happen

Mains voltage could kill a person so, please be careful when wiring mains wires
Crimp electrical connections where possible.
For mains wires, 12 AWG copper wire is recommended
For 24v wires, 22 AWG fine strand wire is recommended

Mechanical Components

Components	Spcifications	Misumi Search Term	Quantity
Extruder	Orbiter v1.5	---	1
Smooth Idler (Highly spsific, using this link is hightly recommended)	GT2® / OD: 12mm / for 6mm Belt / 5mm	---	4
Toothed Idler (Highly spsific, using this link is hightly recommended)	GT2® / 20T / for 6mm Belt / 5mm	---	6
Drive Pulley	GT2® / 20T / for 6mm Belt / 5mm	---	6
Timming Belt	GT2® / Width: 6mm Belt / Length: (in Calculator)	---	2
Liner Rail	MGN12H / Lengths: (in Calculator or CAD)	---	3
Liner Rod	Diameter: 12mm / Heat treated steel / crome coated	PSFU12(Recommendation)	2
Liner Bearing	LM12LUU	SLMUW12(Recommendation)	2
XY Motor Mount Bearing	625 Bearing	---	2
Idler Pin	Diameter: 5mm / Length: 30mm	---	10
XY Motor Mount Pin	Diameter: 3mm / Length: 15mm	---	2
Belt Tensioner Pin	Diameter: 3mm / Length: 35mm	---	4
Print Head Prin	Diameter: 3mm / Length: 47mm	---	2
End Stop Tigger Prin	Diameter: 3mm / Length: 10mm	---	2
End Stop Mount Prin	Diameter: 3mm / Length: 12mm	---	2
Bed Bracket Collar	OD: 6mm / ID: 3mm / Length: 12mm	KNCLSS3-6-12(Recommendation)	4
Bed Spring	OD: 6mm / ID: >3mm / Length: 15mm	SWF6-15(Similar spec spring will be hard to find)	4

Frame: The 3D printed parts of the Penteract are spcifcly designed to use Misumi aluminum 3030 extrusions (not the case for 1515 extrusions)

Components	Spcifications	Misumi Search Term	Quantity
3030 Aluminum Extrusions	Lengths: (in Calculator or CAD)	"GFS6-3030"(Standard) or "GNFS6-3030"(Economy) (additonal machining will be requred, Refer to the CAD)	(in Calculator or CAD)
3030 Aluminum Extrusion for liner rail Mouting	Lengths: (in Calculator or CAD)	HFSP6-3030	2
1515 Aluminum Extrusion	Lengths: (in Calculator or CAD)	HFS3-1515	(in Calculator or CAD)

Assembly Guide

Insert the 45mm hex head M5 screw FIRST in the "P_Belt_Tensioner" during assembly.
All the Brackets that attach to the 3030 aluminum extrusions will use 15mm button head M6 screws to attach
All the Brackets that attach to the 1515 aluminum extrusions will use 8mm socket head M3 screws to attach
A rubber, wooden, or plastic mallet/hammer could be necessary to tap in the press-fit components

Recommended Tools: Quality will matter to an extent

2.5mm ball-end hex screwdriver
4 hex Allen wrench with ball-end
5 and 6 mm hex Allen wrench
Nipper
Rubber mallet
Ferrule Crimpers
Engineer PA-09
Engineer PA-05
PTFE based synthetic grease

Cradits and Inspration

Main Design Architacture inspration:

Elements of 3D Printed Parts Design:

Prusa i3 Bear Upgrade

This design uses:

E3D V6
BL touch v3
Orbiter v1.5

Thank You

All the members of the Penteract Discord server for supporting the project
Members in "Hypercube Evolution Pro modified" Facebook group where this project started
Members of the "Annex-Engineering" Discord server

Change-log

10 March 2019: "X-Carriage" bolt insert update
11 March 2019: "E3D Anti-Backlash Nut Mount_Rear" nut insert update
11 March 2019: "E3D Anti-Backlash Nut Mount_Front" nut insert update
11 March 2019: "Y-Carriage_Left" nut insert update
11 March 2019: "Y-Carriage_Right" nut insert update
11 March 2019: "Heat Bad Support Screw Cap" screw insert update
11 March 2019: "Heat Bed Support Screw Mount" nut and screw insert update
12 March 2019: "XY-Idler Mount_Left" nut insert update
12 March 2019: "XY-Idler Mount_Right" nut insert update
16 March 2019: "Z-Rail Mount_Front" fillet update
16 March 2019: "Z-Lead Screw Holder" length update
16 March 2019: "Z-Stepper Motor Mount_Left/Rear" motor clearance update
16 March 2019: "Z-Stepper Motor Mount_Right" motor clearance update
16 March 2019: "X-Carriage" motor clearance update
16 March 2019: "Belt Clamp" clearance update
17 March 2019: "Conner Bracket" notch elimination update
17 March 2019: "Heat Bed Mount_Center" chamfer update
17 March 2019: "Heat Bed Mount_End_Type 1" chamfer update
17 March 2019: "Heat Bed Mount_End_Type 2" chamfer update
20 March 2019: "E3D Anti-Backlash Nut Mount_Rear" clearance update
20 March 2019: "E3D Anti-Backlash Nut Mount_Front" clearance update
20 March 2019: "Leveling Screw Mount" added
20 March 2019: "Heavy Electronic Frame Mount" added
20 March 2019: "Z-Lead Screw Holder" clearance update
20 March 2019: "Z-Stepper Motor Mount_Right" clearance update
20 March 2019: "Z-Stepper Motor Mount_Left/Rear" clearance update
29 April 2019: Overall Update
30 April 2019: "Y-Carriage_Right" chamfer mistake fix
16 June 2019: Overall Update
17 June 2019: "XY-Idler_Bottom_Plate" chamfer added
18 June 2019: "XY-Idler_Top_Plate_Left" hole eliminated
19 June 2019: "XY-Idler_Bottom_Plate" stiffened
25 June 2019: "End-Stop_Activator" chafer added
25 June 2019: "End-Stop_Mount_Back" raised
25 June 2019: "End-Stop_Mount_Front" raised
25 June 2019: "X-Carriage_Top_Plate_x2" raised and chafer added
25 June 2019: "X-Carriage_Bottom_Plate_x2" raised and chafer added
25 June 2019: "BLTouch_Mount" Added
01 July 2019: "XY-Idler_Top_Plate_Right" thickened
01 July 2019: "XY-Idler_Top_Plate_Left" thickened
01 July 2019: "Z-Rail_Carriage_Mount_x2" stiffened
23 November 2019: Overall Update
24 November 2019: "Bed_Bracket_#" added
25 November 2019: "Z_Motor_Mount_x2" lengthened
25 November 2019: "XY_Idler_Mount" clearance update
25 November 2019: "Z_Motor_Mount_x2" simplified
25 November 2019: "Z_Motor_Mount_x2" changed
25 November 2019: "Z_Rail_Holder_x2" chafer added
25 November 2019: "BL_Touch_Mount" lengthened
31 December 2019: "XY_Motor_Mounts" redesigned
01 January 2020: "XY_Idler_Mounts" corrected
01 January 2020: "Belt_Tensioner_x4" added
02 January 2020: "Center_Bed_Bracket" added
04 January 2020: "Center_Bed_Bracket" changed
04 January 2020: "Z_Rail_Carriage_x2" deleted
04 January 2020: "Z_Rail_Carriages" added
27 January 2020: "Center_Bed_Bracket" clearance update
24 February 2020: "Hemera" update
25 February 2020: "X_Carriage_Boost_Plate" added
25 February 2020: "X_Carriage_Boost_Plate" 40mm M3 update
25 February 2020: "X_Carriage_Rear_Plate" 40mm M3 update
25 February 2020: "X_Carriage_Front_Plate" 40mm M3 update
25 February 2020: "Hemera_X_Carriage_Front_Plate" update
25 February 2020: "Hemera_X_Carriage_Rear_Plate" update
25 February 2020: "Hemera_X_Carriage" update
27 March 2020: "Y_Carriage_Plate_for_18mm_Idler_&_Pulley" added
27 March 2020: "XY_Idler_Mounts_for_18mm_Idler_&_Pulley" added
27 March 2020: "XY_Motor_Mounts_for_18mm_Idler_&_Pulley" added
27 March 2020: "Y_Carriage_Top_Plate_for_18mm_Idler_&_Pulley" added
27 March 2020: "Z_Carriages" clearance update
25 August 2020: "Print Setting" update
26 August 2020: "4040_type" added
25 August 2020: "Z_Rail_Motor_Mount" update
24 October 2020: "P_Z_Carriage_x2" added
07 March 2021: Overall update
