Modelo 3D Push_Block_Repaired por Maverick_makes no Thingiverse

Descrição

Update 3/1/19 I modified three of the existing parts to improve the strength and rigidity.

bottom_Repaired_V2.stl i doubled the thickness of the front and back tabs that bolt into the main, and doubled the thickness of the bottom additionally i rounded all the joints where the part would be at risk of breaking due to stress.

routerplate_v2_repaired_V2.stl i cleaned up the model a little more removing unneeded polygons and rounding all the seams that would be under stress to decrease the risk of cracks at those joints.

side_plate_repaired_V2.stl i curved all the seams and corners that were not mating surfaces, to improve the rigidity of the part and to decrease the likely hood of a crack

Once i get all these parts printed i will include them in my final make, and share a comparison between the original part and the improvements made.

Original Post When i went to print some of these files i noticed holes in the tops of some of the models See Picture 2 (Tops of Models are Red) I went through and repaired all the models (See Picture 1), Hopefully others won't see the same issues and can enjoy this great model. If you experience any issues please let me know so i can update the specific files

Thanks again for the great Model Trobinou

Thingiverse

Push_Block_Repaired

135
Curtidas
0
Downloads
241
Coleções
2
Impressões
Tags
Push block router router table table saw
Licença Creative Commons - Attribution - Non-Commercial - Share Alike
Arquivos (14)
bottom_Repaired.stl 327.6 KB
Side_Repaired.stl 699.5 KB
Knob.stl 302.6 KB
Stabilizing_Plate_Repaired.stl 365.6 KB
Main_Repaired.stl 842.3 KB
Handle_Repaired.stl 14.5 MB
Side_Plate_Repaired.stl 741.8 KB
router_plate_v2_Repaired.stl 468.6 KB
Inser_Repaired.stl 207.2 KB
Knob_bottom_back.stl 308.7 KB
Tail_Repaired.stl 6.5 KB
bottom_Repaired_V2.stl 380.5 KB
routerplate_v2_repaired_V2.stl 610.1 KB
side_plate_replaired_V2.stl 983.7 KB
