Please download this model (for free) via Printables! https://www.printables.com/model/136892-tevo-tornadocr10-bed-chain *

Cable chain for the heatbed of the Tevo Tornado, it might also work with the CR-10 but I did not test that.

I switched from my anet a8 to the tevo tornado and I missed the cable-chain for the bed. Especially because there is no strain-relief for this printer.

I used the frame-piece of "stevenfayers" and slightly modified it so you can equate the z-height of the bed and the mounting point. I used the trusty old chain of "sukhoi27" and modified it slightly to fit the cables. Now you can just put in the cables and close the chain link off with a pin. For the strain-relief and bed mount I used the design of "Pemic' and just pasted a chain link on it

Hardware:

• 3 zip ties for the strain-relief,
• 2x t-bolt nuts + 2 M4 bolts to connect to frame.
• 2x m3 bolts and nuts for the last chain

Print: 5x "chainlinks open 4x" (you need 18 chain links) 18x "cable holder pin" 18x "cable holder cap" 1x "edited frame mount" 1x "mount last chain" 1x "bed mount with strain-relief" or "Carriage mount with strain relief"

Visit our site if you want to modify/design something or to order 3D printer parts online; https://voxel3d.nl/ (currently only possible in europe)

Watch it here: https://youtu.be/d3aexUMfAys
