Modelo 3D Customizable storage/components drawer por ALittleSlow no Thingiverse

Descrição

A remix of DonJaunito's quality remix. These are mostly his instructions.

A replacement storage/components box/drawer that you can customize via Customizer.

  • Check or adjust the drawer parameters. You can add or remove dividers by editing the "DPos" vector. For example, for two dividers 30 and 60 mm from the front, enter [30, 60].
  • Render the "Drawer", the "Handle" and the "Divider", or all of them together.
  • Print one of each (more dividers if needed) and assemble. You may have to glue the sliders of the "Handle" in place, but the default tolerance ("leeway") made it unnecessary for me.

All can be printed without supports, even if the bottom of the drawer might need some filing/sanding. Mine didn't.

The source file is (heavily) commented.

Version 1.1

Remixed by Green Ellipsis LLC - Brian Alano

  • Added lead-in to slots for easier assembly
  • Made parameters Customizer-friendly
  • Created preset for Akro-mils 10144 (and 10164) storage units
  • Added all-in-one render

Version 1.2

Updated comments and added preset for Akro-mils 10144 large drawer

Thingiverse

Customizable storage/components drawer

188
Curtidas
0
Downloads
235
Coleções
Tags
Akro-Mils customizable customized customizer divider drawer Drawer Dividers openscad parametric storage Storage Box
Licença Creative Commons - Attribution - Non-Commercial - Share Alike
Arquivos (10)
Demo_1.stl 489.9 KB
Akro-mIls_10144-10164_small_V1.1.stl 373.8 KB
Akro-mils_10144_small_no_divider_V1.1.stl 317.6 KB
Default_Handle.stl 14.6 KB
Default_Drawer.stl 429.7 KB
Default_Divider.stl 15.1 KB
Akro-mils_10144_large_handle_V1.2.stl 14.2 KB
Akro-mils_10144_large_divider_V1.2.stl 15.2 KB
Akro-mils_10144_large_set_V1.2.stl 378.7 KB
Akro-mils_10144_large_drawer_V1.2.stl 349.8 KB
