Single Print Padlock

My vision for this was to create a lock that would keep small children out but still let others have easy accsess

This is a first draft (now a 4th draft "Padlock 4" as of 2-18-2018)

Any makes and/or suggestions will be appreciated

Padlock 3: The shackle in "Padlock 3" is 15mm taller than version 2 and the amount of supports needed has been reduced by a fair amount. (see print settings)

The slot in the bottom for turning the lock has been changed to a hex and two holes have been added to spread out the force needed to break it free. ( I will make a key for this if needed)

An extra hole has been added to the side to help remove supports (may not be needed but thought it would help)

Padlock 4:

more supports were removed to help break the lock free.

some side ports were not needed and were removed

this version has a bigger key hole
