UPDATE: Moved the hole for cable towards the center of the 2 halfs. This allows for better cable management with a teensy or pro micro inside of it.

I designed a tiny split keyboard. I only have the matias version done, but the cherry mx version will become available if anyone shows interest.

Why only 32 keys? -I only had 32 extra keys from my last build.

Won't this suck with only 32 keys? -Probably. I designed it to learn about split keyboards with qmk firmware.

Those columns look very staggered. -They are. People with bigger hands shouldn't have a problem. I have small hands. They're barely too staggered for me. Should be fine enough for testing.

Why is it called the SANIC keyboard? -Gotta go fast.

Internal clearance for wires, diodes, and controller is ~5mm. This should be plenty if you use a pro micro. I'm pushing the limits with a teensy I had laying around.

Printed it on a Monoprice Select Mini v2 Fits within 120x120x120 build volume. Might need to add a few mm to the x and y in your slicer to get it to fit if you're on a printer that small though.

Any 8mm m3 screws should skip the bottom panel and tap into the holes in the top of the keyboard. should provide a nice tight fit.
