Modelo 3D SMD Strip bin for Mx SMD Roll por pbechard no Thingiverse

Descrição

This is a remix of two great products:

Mx SMD component strip holder https://www.thingiverse.com/thing:2186862

SMD Strip Dispenser Tray for Mx SMD Roll https://www.thingiverse.com/thing:2717152

I was really impressed by how these two products came together. When I was testing out the holder, a few SMD pieces fell out of the strip, and I had nowhere to save them alongside the strip storage container they belong to. I did see that Mx also has an insert for such storage, but I didn't want a separate box for just a few loose pieces.

My solution was to stretch both the original strip holder and the dispenser cover to allow for a bin that could hold the loose pieces. When closed up, you'll have the loose and sealed pieces all in one spot.

After printing my sample, I added a label to the "top" side so that you don't accidentally open the container upside-down and spill those little SMD pieces everywhere. There's also a small recess to put a printed label or sharpie marker label on that "up" side.

Thingiverse

SMD Strip bin for Mx SMD Roll

39
Curtidas
0
Downloads
53
Coleções
Tags
mx smd smd smd storage smd box smd components smd led smd roll smd tray
Licença Creative Commons - Attribution
Arquivos (2)
SMD_holder_cover.stl 158.6 KB
SMD_holder_body.stl 213 KB
