3D printed Lunar Phase Clock, designed by G4lile0 2016

Update 25/02/2017 new code version V 4.0 Clock Status is now stored on the RTC NVRAM, this mean that after power failure, clock will return to the old status, moon mode, and alarm configuration instead of load defaul configuration.

Since there isn't a SuperMoon everyday, make one for your bedside table!!

If you don't know what to print with your 3D printer, here you have an easy project. Build a 3D printed Lunar Phase Clock for your desk.

Features: (check the video)

• Open Tools (Ubuntu / FreeCAD / Arduino)
• Open Source / Hardware
• Cheap HW (Arduino, cheap LCD..)
• Only 79 grams of filament.
• Precise Lunar Phase Simulation
• Detailed 3D printed Lunar model by Dexter_New_Materials (http://www.thingiverse.com/thing:1014620)
• Alarm
• Wake-light alarm mode
• Date
• Thermometer
• Hygrometer
• Lamp mode
• Moon FX modes (Relax, Party... )
• Bright control
• Adjustable tilt

Parts List:

• Arduino compatible Nano (Atmel ATmega328)
• 0,96'' OLED 128x64 with SSD1306 chip
• APA102C led strip (18 leds)
• Tiny RTC (DS1307 real time clock + 24C32 EEPROM)
• DTH11
• Buzzer
• 3 Push Buttons

Source available on GitHub: https://github.com/G4lile0/Arduino_3dprinted_Lunar_Phase_Clock

For further info: http://www.instructables.com/id/3Dprinted-Lunar-Phase-Clock/

Video Created under Ubuntu with OpenShot video Editor. Music : Sport Action

Reloj con fase Lunar impreso en 3D diseñado por G4lile0

Como no todos los días hay una SuperLuna ¡¡fabrícate una para la mesilla de noche!!

Si no sabes que imprimir con tu impresora en 3d, aquí tienes un reloj con fase lunar para tu mesa.

• Creado solo con herramientas libres (Ubuntu / Freecad / Arduino)
• Open Source / Hardware
• Electrónica económica (Arduino, LCD)
• Tan solo 79 gramos de filamento
• Precisa simulacion de la fase lunar
• Modelo detallado de la luna by Dexter_New_Materials (http://www.thingiverse.com/thing:1014620)
• Reloj analogico y digital
• Alarma con simulación de amananecer
• Alarma
• Fecha
• Termometro
• Monitor de Humedad
• Lampara
• Modos Demo (Disco /Relax...)
• Control de brillo
• Inclinación regulable

Componentes:

• Arduino compatible Nano (Atmel ATmega328)
• 0,96'' OLED 128x64 with SSD1306 chip
• APA102C led strip (18 leds)
• Tiny RTC (DS1307 real time clock + 24C32 EEPROM)
• DTH11
• Buzzer
• 3 botones.

Fuentes disponibles en GitHub:

https://github.com/G4lile0/Arduino_3dprinted_Lunar_Phase_Clock

Para mas información: http://www.instructables.com/id/3Dprinted-Lunar-Phase-Clock/

Vídeo creado bajo Ubuntu con OpenShot video Editor. Musica : Sport Action
