I needed some kind of enclosure for a nixie clock (PCB and its gas lamps). Sometimes, one could easily get a 300V hit, which is not deadly due to super low power of the device, but still unpleasant. And although gas lamps have a nice warm glow, at night they would shine just too bright, so I had to take that in to account. I wanted something retro looking, like an old military devices, or an old gas lamp radio.

How much I succeeded in capturing the look is for you to decide.

The PCB's already came with some nuts and bolts, so I just used those for the assembly. Otherwise, the openings on the front cover are 2.5mm, and the accepting parts on the case are 2mm in diameter. I used are 2x8mm phillips bolts.

On the side of the case there are 3 openings, one for the UBS cable, other two for the clock adjustments.

Printables:

• Case: I used ASA, just because I had it in the printer. Otherwise I believe the model could be printed with any desired filament. No special setting. Just some supports for the overhangs.
• Cover(s): 2 covers, a mesh and a solid one for more stealthy look

Non-printeables:

• a simple cheap nixie clock PCB, from Ali and alike
• IN-12a nixie tubes
• regular 5V output wall charger

AliExpress link to the PCB used:

[https://www.aliexpress.com/item/1005002287761858.html?spm=a2g0o.productlist.main.9.3a0ejY61jY61TS&algo_pvid=9c3e1c88-7b42-4111-a18c-662df46e6b84&algo_exp_id=9c3e1c88-7b42-4111-a18c-662df46e6b84-4&pdp_npi=4%40dis%21CHF%2120.63%2116.50%21%21%2122.54%2118.03%21%402101c5a717181776534861104ed9e1%2112000019924031071%21sea%21CH%212037906509%21&curPageLogUid=0K4TdmY00pKr&utparam-url=scene%3Asearch%7Cquery_from%3A](https://www.aliexpress.com/item/1005002287761858.html?spm=a2g0o.productlist.main.9.3a0ejY61jY61TS&algo_pvid=9c3e1c88-7b42-4111-a18c-662df46e6b84&algo_exp_id=9c3e1c88-7b42-4111-a18c-662df46e6b84-4&pdp_npi=4%40dis%21CHF%2120.63%2116.50%21%21%2122.54%2118.03%21%402101c5a717181776534861104ed9e1%2112000019924031071%21sea%21CH%212037906509%21&curPageLogUid=0K4TdmY00pKr&utparam-url=scene%3Asearch%7Cquery_from%3A)
