Modelo 3D Coordinate-Cube 9 Axis por Hirte no Printables

Descrição

I found a lot of 6-Axis Coordinate Cubes to print but i wanted one to also show Axis U,V and W. Took me some time (new to Fusion360) but here it is.

You need to print all Parts once except for the Tip, that needs to print 3 times.

Printed it on my Mini+ and most Parts snapped together without the need for Glue.

Mounting Steps:

1 - The inserts go into the respective Pins (U into X, V into Y and W into Z), then you snap or glue the Tip to the insert - careful not to glue it to the pin, the insert-tip-combo needs to move freely!

2 - Add the Rings to the Pins (A on X, B on Y and C into Z) with the chamfered side toward the Tip of the Pins. They schould sit snug but still be able to rotate.

3 - Add the Pins into the body. If you use glue make sure to pull the inserts out until the glue hardens, otherwise the inserts become stuck to the body.

There is a groove on one side each tip to be able to pull the inserts out to reveal Axis U,V and W.

Printables

Coordinate-Cube 9 Axis

Publicado em 6 de abr de 2024

5
Curtidas
57
Downloads
Categoria Other 3D Objects for Learning
Tags
cube xyzcube axis koordinatensystem
Licença Creative Commons — Attribution — Noncommercial
Arquivos (11)
Body.step 2.4 MB
Pin X.step 257.5 KB
Pin Y.step 333 KB
Pin Z.step 204.9 KB
Insert X (U).step 110.8 KB
Insert Y (W).step 173.2 KB
Insert Z (V).step 268.4 KB
Ring X (A).step 279.2 KB
Ring Y (B).step 304.5 KB
Ring Z (C).step 226.6 KB
Tip.step 18.5 KB
