Knife Sharpening Tool V2.1 (with video)

This is the fully revised Version 2.1!

Bill of material:

Suitable sharpening stones set(aff): [https://s.click.aliexpress.com/e/_onjGrqw](https://s.click.aliexpress.com/e/_onjGrqw)
OR Individual sharpening stones (aff): [https://s.click.aliexpress.com/e/_oCIZKV4](https://s.click.aliexpress.com/e/_oCIZKV4)
1x M3x12 cylindrical head bolt (X, spherical housing)
1x M3 nut (X, spherical housing)
1x M4x16 hex head bolt (Z, adj knob)
1x M4x16 cylindrical head bolt (Y, file handle)
2x M4 nuts (Z&Y)
2x M5x20 cylindrical head bolt (Z, bottom stay)
1x M5x20 hex head bolt (bed, blade stay)
1x M5 washer (bed, blade stay)
2x M5 nut (Z, bottom stay)
1x M5 thumb nut (bed, blade stay)
10mm diameter x 180mm aluminum rod/tube
10mm diameter x 300mm aluminum rod/tube
6mm diameter x 280mm aluminum rod/tube

10x 10x2mm disc magnets ([https://geni.us/Qgif](https://geni.us/Qgif)) Sharp knifes are essential in your kitchen. I was inspired by another 3D printed knife sharpener ([http://www.dr-henschke.de/Messerschleifer.html](http://www.dr-henschke.de/Messerschleifer.html)) and adapted the design for relatively cheep Chinese water stones as you can find them on Aliexpress. Additionally I simplified the geometry to reduce the number of parts and to make the assembly easier.
