Modelo 3D Marble Fidget Spinner por James Steiner no Printables

Descrição

I had a couple marbles and wanted to design my own take at a fidget spinner. You do need a marble to use this correctly. Needs to be 24mm - 14mm in diameter. I've uploaded three different sizes. The standard size works for marbles as small as 16mm but i've added a small version specifically for those marbles. Tighter fit will lead to faster spinning. I've also added a large version for 24mm marbles. This is a simple press fit design. No glue needed, especially if you plan on removing the marble after or to switch it out.

I would print at .2 or smaller.

3 walls

20% gyroid

5 top and bottom layers

I added a printable ball too. Fits the standard version best. Print two of the halves. Glue them together. Hole in the middle is for excess glue to run into.

Ball:

3 walls inner/outer/inner or if you do two walls do outer/inner for best dimensional accuracy

100% infill

adaptive layer height or .1 mm layers

no support

Printables

Marble Fidget Spinner

Publicado em 25 de jan de 2024

15
Curtidas
52
Downloads
1
Impressões
Categoria Other Toys & Games
Tags
spinner fidget easy fidgetspinner marble easyprint
Licença Creative Commons — Attribution — Noncommercial
Arquivos (7)
21mm small marble stud.stl 1.2 MB
21 mm small marble hole.stl 1.2 MB
marble hole standard 23mm.stl 1.2 MB
marble stud standard 23mm.stl 1.2 MB
24.5 mm large marble stud.stl 1.2 MB
24.5 mm large marble hole.stl 1.2 MB
Marble.stl 850.5 KB
