Please pay attention to a new version of this model, published here: [https://www.printables.com/model/1044261-case-feedercollator-update](https://www.printables.com/model/1044261-case-feedercollator-update) .

Complex model, gcode not included, as modifications according to your application are assumed.
Notes and other major components sample references:

1. Motor mount designed for JGA25-370 Geared motor DC motor 12V 5rpm ( [https://www.aliexpress.com/item/32987942205.html](https://www.aliexpress.com/item/32987942205.html) )
2. Bullet drop adapter designed for:

• proximity sensor LJ12A3-4-Z/BY ( [https://www.aliexpress.com/item/32859197984.html](https://www.aliexpress.com/item/32859197984.html) ). Model assumes thread cutting instead of printing for better accuracy. Sensor purpose is bullet counting. Cut the thread by 12mm tap, note the pitch (fine pitch 1,5mm).
  -Mr.Bulletfeeder output spring Large for pistol calibers ( [https://www.doublealpha.biz/mrbulletfeeder-output-spring-and-extension-adaptor](https://www.doublealpha.biz/mrbulletfeeder-output-spring-and-extension-adaptor) ).

1. Case bucket dimension is too small for rifle cases.

I recommend to use wooden anchor pin to prevent motor gear or feeder parts damage in case something goes wrong, at least during the setup phase.

Tribute to [https://github.com/dyspreficks/ShoeboxCaseFeeder](https://github.com/dyspreficks/ShoeboxCaseFeeder) .

Print instructions

For Anchor_case, Bucket_stand, Upper_end1_case and Upper_end2_case PLA recommended.
Other parts PLA and/or PETG according to your preferences. Except Anchor part, no supports are required.
For large parts - eg. bucket etc., 0,2mm layer is OK.
For Anchor, brim and support on build plate are required.
Drop_tube - remove the stabilizing "skirt" after print!
