This is a weights rack inspired by your neighbourhood gym in desk-size for your pens to show off just how much you love to lift pens while at work.

The model files are in the right orientation for printing and do not require any adjustments before slicing.

The connectors may require post-processing due to very tight tolerances, i.e. filing some material off of the press-fit connectors (colored surfaces).

Assembly

Same for left and right.

Make sure both connectors are all the way in and fit snugly.

Pay special attention to the lower connector to sit flush with the bottom of the main legs so it has a secure stand and does not wobble.

Arrows copyright: Isometric Arrow Vectors by Vecteezy

The barbell requires some additional hardware:

• Option 1 (as seen in the pictures)
  • Two 70mm M5 screws
  • Three nuts
  • Four washers
• Option 2
  • 140mm M5 threaded rod
  • Four nuts
  • Four washers

→ Print 4 disk halves (file included “WeightsRack_Disk_4_halves.3mf”) and assembly with the optional hardware as required

Model dimensions:

If you need any adjustments to the model for your specific use-case just message me at:
philippebraum@gmail.com

Changelog

--- 13.06.23
> Revised weight plates design

Disclaimer:

The model is 100% my own creation.
However, I got the idea for the model from other offers on the internet selling this product.
I decided to create & build my own model instead of buying one.
This is why I decided to make this model free to use for any purposes (incl. commercial) only with attribution required.
