Litho lamp customizable
You can set custom size each side also can set many more options
you can find allso here [https://www.thingiverse.com/thing:2771687](https://www.thingiverse.com/thing:2771687)
what you need
generate lithophane picture on site [http://3dp.rocks/lithophane/](http://3dp.rocks/lithophane/)
you need openscad have install on your pc
set parameters generate each parts one by one and can print it
STL file here is only for visualisation do not print it

You need 8 M3x20 screw
4 x M8x10 for cable holder
Some tips

Only you need to care the main Height must be higher min 5 mm from the picture and
weight must be 25 mm bigger.
You can have set all 4 picture different but the lamp size need to set for the biggest picture. and the lamp holder size.
Roof and Leg will be over the main height.
If will use main voltage (220V) and you has no experiences please please dont do this!!!

The holes I designed little bit smaller you need drill it with 3.3 -3.5mm
by pillars and bottom or top where comming the lamp holder 2.5mm and cut threat M3

Note: don´t export like all part this is only for check setting export all part separatly ( if all pictures hase same size you need export Pillars only ones and print 4 times)

Print instructions

Print PETG
