System to mount LED panels with aprox. 9,5mm thickness to the ceiling.

Print all parts with 0.20mm layer height. The feet need to be sturdy, so print them solid or at least with 4-5 walls, so they don't break while mounting. For each mounting point, you need 3 parts:

• a foot,
• a turner,
• and a gripper: Most of the time you need the corner parts, only with large or long LEDs it makes sense to attach 2 more fasteners to the long sides (named "middle") .

I printed all the parts in PETG 2 years ago - no problems until now.

It's an easy print. If you need oher dimensions, let me know.
