A magnetic case for 12 MicroSD cards

This case prints in 2 parts on any printer, and uses 2 magnets (glued with super-glue) to keep it closed and keep your micro-sd cards organized and protected.

You will need two round magnets with a 15mm diameters and 3mm thickness (smaller magnets should work too).

Features:

• Prints on any FDM printer with no supports, no raft, and standard settings
• Magnetic lid is easy enough to open with one hand, but won't open in your bag
• Fits 12 micro-sd cards, accounting for the possible variation in their dimensions between different manufacturers (mainly in thickness)
• Slots are shaped according to the cards, so that cards can only fit in 1 way, to keep them organized and consistent
• Spacing between cards is designed for easy access
• A large MicroSD logo on the top cap for easy recognition
• Built in clearances for easy assembly and a satisfying fit

Instructions:

1. Print both parts with their flat faces facing down (the logo requires minimal bridging and does not need supports)
2. Use super-glue (5 second glue) to attach a magnet into the round slot in the center of both parts and allow glue a few minutes to dry
3. Insert your microsd cards with the contacts facing down, and the notch facing inwards

Print Settings

Printer Brand:

Creality

Printer:

Ender 3

Rafts:

No

Supports:

No

Resolution:

0.2

Infill:

15%

Filament: eSun PLA+


Notes:

Printed on the Ender 3 S1 with 60mm/s speed, a standard 0.4mm nozzle, and default settings for PLA.

Category: Gadgets
