A remix of Sneaks excellent ‘Articulating Raspberry Pi Camera Mount’ -camera housing to suit the new v3 Raspberry Pi camera.

The V3 camera has a much bigger sensor and comes with autofocus- quite a big upgrade from the V2 camera. However, the new sensor is significantly bigger.

I changed the camera cover of Sneaks design ( [https://www.printables.com/model/3407-articulating-raspberry-pi-camera-mount-for-prusa-m](https://www.printables.com/model/3407-articulating-raspberry-pi-camera-mount-for-prusa-m) ) to allow for the new sensor, and all fits fine.

There are two designs, a plain front, and a version with a hexagon pattern. If you want a dual-colour hex print like the photo, change filament at 1mm and 2.4mm layer heights (roughly, this will depend on you print layer heights - but you know the drill :) )

If you already have this setup with a V2 camera, you only need to print a new “RasPi Camera V3 Module Cover” - the back should work fine. My remixed back simply aligns the supports with the mounting holes, but the existing back doesn’t seem to cause interference.

I have uploaded my model of the v3 camera module here in case you want to use it for other models; [https://www.printables.com/model/368779-raspberry-pi-camera-module-3](https://www.printables.com/model/368779-raspberry-pi-camera-module-3)

You can check out my other models here: [https://www.printables.com/social/194731-docweebl/models](https://www.printables.com/social/194731-docweebl/models)

UPDATE 07/02/2023  -  I've had a couple of comments that this doesn't fit the wide angle lens version of the camera, and so have added two new files which should suit it according to the documentation. I don't have the wide camera module myself, so can somebody please let me know if the new designs fit okay, or if I need to open up the lens hole a little? Thanks!

UPDATE 08/03/2023 - I have modified “Joe's wood'n 3D”'s [https://www.printables.com/model/103898-connector-box-for-rpi-csi-cables/remixes](https://www.printables.com/model/103898-connector-box-for-rpi-csi-cables/remixes) to include a matching hex pattern on the lid case. Link to the hex pattern version here: [https://www.printables.com/model/418460-raspi-csi-connector-box-hex-pattern-remix](https://www.printables.com/model/418460-raspi-csi-connector-box-hex-pattern-remix)
