This model is now outdated. Check out V2 here!

-----------------------------------------------------------------

Retro TV case based on a Toshiba Blackstripe I made for a Raspberry Pi 3B to run RetroPie and play cartoons. Designed to fit a Pi 3B with a 3.5 inch HDMI MPI3508 LCD display.

In addition to the print you'll need:

• Raspberry Pi 3B (might fit Pi 4 but I haven't tested)
• 3.5 inch HDMI MPI3508 LCD display with HDMI crow connector (such as this one)
• Right angle micro-usb adapter (such as these) to allow power cable to be connected from the back of the TV. Pi 3B uses the “down” version.
• SD card with RetroPie (or whatever you want to run)
• 4x M2.5x5 screws for the shell
• 2x M2.5x8 screws for the antennae
• 2x M2.5x8 screws for the base

Optional:

• 30mm 5V fan (such as this one)

All parts except base, pi_case, and viewport should be printed with supports. The front is printed as multi-material.

RetroPie Notes:

I used the following values in my /boot/config.txt to reduce the display output to 4:3.
overscan_left=-10
overscan_right=65

CHANGE LOG

Feb 13 2023

• Added bracing tab for USB adapter to Base.

Feb 3 2023

• Added speaker gaps to Front grill.

Feb 1 2023

• Added 30mm fan mountable version of Back.
• Added channel gap in Pi Case for fan wires.
• Cut left side corners off Viewport for better fit.

---------------------------------------------------------------------

Have fun!
