Descrição
Sizes
All three sizes are fitted for the Original Prusa i3 MK2/2.5/3/4 3D printer.
Small size - 245x205x80 mm
Medium size - 245x205x150 mm
Large size - 245x205x220 mm
Only small size is equiped with front handle. Medium and large size can by optionally equiped with tiltable side top handles. All three sizes can be assembled with or without top handle (for medium and large size is recommended).
The smaller size of SBox for Original Prusa MINI is available - SBox for MINI - stackable toolbox system is intended for printing on the Prusa MINI size 3D printer.
Assembly
list of non-printed parts
- 8 pcs - metal axis 36(35)mm x (2.8 - 3)mm or M3 screw with internal hex head
- 8 pcs - metal axis 39(40)mm x (2.8 - 3)mm or M3 screw with internal hex head
- 4 pcs - metal axis 22(20)mm x (2.8 - 3)mm or M3 screw with internal hex head (for Medium and Large size)
- 2 pcs - metal axis 24(25)mm x (2.8 - 3)mm or M3 screw with internal hex head (for top with handle)
- 2 pcs - metal axis 26(25)mm x (2.8 - 3)mm (for hinges)
You can use Locating Dowel or Cylindrical Pins or Stainless Steel Shafts in M3 diameter (lengths 35mm, 40mm, 25mm, 22mm) as a metal axis.
T-shirts
Support me & Buy a T-shirt
Extensions
All parts of SBox - stackable toolbox system
Double cantilever box for MK2/3/4
SBox for MK2/3/4 - stackable toolbox system
