Object description:
This battery holder fits to the Gridfinity System.
The provided sizes are from 1x1 up to 5x5 segments. Each segment stores 9 batteries size AAA. So you can store a maximum of 225 batteries, if you really want.
Update 2024-02-23:
- Added versions with sideplugged magnets
Update 2023-10-14:
- Added comment to support in print settings.
- Added document “Gridfinity - an example comparison of weight and printing time.pdf”.
Comments:
The boxes can be printed in vasemode. My recommendation is using at least a 0,6mm nozzle, better a 0,8mm nozzle.
Make sure, that you print as many bottom layers as you need for at least 5,4mm bottom height.
The overall height is slightly higher than actually necessary. Shortening is much easier than lengthening. I recommend shortening the overall height to 21 mm.
You can secure blocks permanently with M3 countersunk screws, or temporarily with 6x2mm magnets.
If you are looking for a the AA-size version, you can download it here: [https://www.printables.com/de/model/246915-battery-box-aa-gridfinity-vasemode-15-different-si](https://www.printables.com/de/model/246915-battery-box-aa-gridfinity-vasemode-15-different-si)
The version for 9V-batteries you can download here:
Print settings:
Material: PLA, PETG or ABS/ASA.
Layer height: 0,4mm
Nozzle diameter: 0,8mm
Vasemode: yes
Brim: no
Support: paint on support for the magnet holes recommended
Battery Box - AAA - Gridfinity - Vasemode - 15 different sizes
Publicado em 28 de fev de 2024
