This is a remix of Ryan Millar's Honeycomb Display Shelf. However, the design was used as visual inspiration, I am unsure if they are dimensionally similar.

I wanted to add a new variation with a front panel.

Printing : PLA

Frame

Infill: 20% Gyroid

Layer height: .2mm

Supports: Support enforcers only. Snug style. V1.1 I found it best to support the angled bracers. shown in GCODE.

V2 I separated the angled brace and added alignment tabs with .12mm tolerance. I added supports for the alignment tabs on the angled brace and for the vertical alignment holes on the wall plate. Cuts down printing time significantly! The same infill plate can be used on version 1 and 2

Infill Plate

Easily customized!

Layer Height: .2mm

No supports needed if larger face is on plate.

Top/Bottom Layers: 0

Infill: I used honeycomb at 14%
