Core items to print:

1. tsr3__CASE_r2_SIDE_ONE

2. tsr3__CASE_r2_SIDE_CONNECTOR

3. tsr3__CASE_r2_SIDE_TWO

Faceplates to print (optional):

• tsr3_BLANK_gen

• tsr3_TS_gen_R2

These are used for the connection sides where the M3 screw heads reside (really only need two printed)

• tsr3_TS_gen_R2 -con

• tsr3_TS_gen_R2 -con

(I recommend importing multiple faceplates onto one print plate to save time)

The direction for the faceplates should not matter. However, I put the side where no wall on the bottom side of the rack.

Sliced using .20m speed preset. No supports needed.

Use M3 Female Thread Knurled Nuts to connect the parts (six in total used)

M3 *12 screws used (six in total used)

In the future, the screws should be in an easier to screw location.

Originally designed for one toggle switch. See file ts7 for the original design.
