Based on the spice rack for ikea, but redesigned for my own dimensions and tolerances: [https://www.printables.com/model/579983-ikea-rajtan-spice-rack](https://www.printables.com/model/579983-ikea-rajtan-spice-rack). My hex shaped holes are different, only used the idea as inspiration and use the same fastening method but designed the model completely from the ground up for my wishes. For this reason I added attirbution but wouldn't call it a remix as such.

I also added a set of 'cut off' versions to be used on top, to store other nick-nacks which don't fit inside the spice holders.

I used SolidPython  ([https://github.com/SolidCode/SolidPython](https://github.com/SolidCode/SolidPython)) which is essentially a wrapper for OpenScad ([https://openscad.org/](https://openscad.org/)), making the design parametric, you might still need to tweak some parameters (such as how large the holes are) if you make it much smaller or larger.

Both a solid version and one with 'material saver' hexes are used which are 90g and 60g respectively, but the print times of the solid versions are shorter.

I use m2.5 x 6mm screws for the vertical connections with coresponding hex nuts, these are quite snug so you might need to add more tollerance depending on your hex nuts. For horizontal connection I bought a m3 x 1meter rod, which i'll cut  to size once done.

Fun fact, I had a failed print half way through on one batch of 3, I used these on the forward edge. As the side and back have identical holes it matches up nicely!
