Key Features:

• Replaceable Blade System: When the edge gets dull or damaged, simply print a new blade and slide it into the handle.

• Eco-Friendly & Cost-Effective: Save filament by only replacing the part that wears down.

• Secure Fit: The blade is designed to snap firmly into the handle, providing a stable platform for scraping.

• Bed-Friendly: 100% plastic construction ensures your build plate stays scratch-free.

Why Modular?

Scraper edges inevitably wear out over time. By making the blade a separate part, you can:

1. Keep the same comfortable handle indefinitely.

2. Experiment with different materials (e.g., a PETG handle for durability with a PLA blade for stiffness).

3. Always have a fresh, sharp edge ready to go.

Print Settings:

• Material:

  • Handle: PLA or PETG (3 perimeters, 20% infill).

  • Blade: PLA is recommended for its stiffness, which helps in getting under prints.

• Layer Height: 0.15mm or 0.2mm.

• Supports: No (Both parts are designed to be printed flat without supports).

Assembly:

Simply slide the blade into the handle's slot until it clicks or seats firmly. If the fit is too tight or too loose due to printer tolerances, you can adjust the "Horizontal Expansion" setting in your slicer or use a tiny drop of glue for a permanent bond.
