3D printer bed scraper with replacable tips (TESTING)

Overview

This customizable bed scraper is an essential tool for any 3D printing setup. Unlike metal scrapers that can scratch and damage your expensive build plates (PEI sheets, glass beds, magnetic surfaces, etc.), this design uses replaceable plastic tips that are gentle on your surfaces while still being effective at removing prints.

Key Features

Replaceable end tips - Print multiple tips and swap them out as they wear down
Build plate safe - Plastic construction won't scratch or gouge your printing surface
Ergonomic design - Comfortable handle for easy grip and control
Cost-effective - No need to buy expensive replacement scrapers
Easy assembly - Simple clip/slot mechanism to attach the replaceable tips

Printing Instructions

Material: PETG or ABS recommended for durability (PLA works but may be less durable)
Infill: 20-30% for the handle, 50%+ for the tips
Supports: None required
Layer Height: 0.2mm standard

Assembly

Print the main handle body
Print 2-3 replacement tips
Slide the tip into the slot on the handle until it clicks into place
Replace tips as needed when they become worn

Usage Tips

Works best on cooled build plates
Use a gentle sliding motion under prints
Replace tips when edges become rounded or damaged
Keep spare tips on hand for quick swaps

Perfect for preserving the life of your PEI sheets, glass beds, and other printing surfaces!
