Descrição
I saw a post on Reddit a while ago about someone who made a stencil for drawing organic chemicals. I always lamented how crappy my resistors looked during my electrical engineering class so I decided to make a quick stencil!
It is a standard credit card size and features a resistor, inductor, capacitor, diode, transistor, op-amp, ground, and battery symbols.
I designed the symbols to work with a 0.5mm mechanical pencil, and they all are based on a 5mm grid so it should look good on most engineering paper.
Print Settings
Printer Brand:
Prusa
Printer:
I3 MK3S
Rafts:
No
Supports:
No
Resolution:
200
Infill:
100
Notes:
I had to let my build plate cool completely before attempting to remove it. The first time I tried on a warm part and it disintegrated so patience is key.
Category: Art Tools
