Modelo 3D Skeleton 3D : Evolved por CGrassin no Printables

Descrição

A makeover of the Skeleton 3D by "Catastrophe" with:

*A new Z axis carriage: more robust and less Z wobble. *A E3D Bowden extruder (instead of the original Aluhotend): better print quality with higher printing speeds. *Screen and attachement for the electronics: ease of transportation and usage. Also adds rigidity to the frame. *Part cooling fan & fan duct: better print quality.

All parts are included in theS3D_Evolved.zip file.

These new parts are fully compatible with the original Skeleton 3D.

I made an article on my website to describe this printer, with build instructions, wiring and source files: [http://charleslabs.fr/en/project-S3D+Evolved+-+compact+3D+printer](http://charleslabs.fr/en/project-S3D+Evolved+-+compact+3D+printer)

Video: [https://youtu.be/Xid42I-h5R0](https://youtu.be/Xid42I-h5R0)

Category: 3D Printers

Printables

Skeleton 3D : Evolved

CGrassin CGrassin (abre em nova aba)

Publicado em 10 de fev de 2022

3
Curtidas
13
Downloads
Categoria Accessories
Tags
3dprinter compact e3dhotend thingiverse
Licença Creative Commons — Attribution
Arquivos (56)
S3DE_E3D_attachment.STL 1.1 MB
S3DE_Zleftcantilever.SLDPRT 206.8 KB
S3DE_Ztopsupport.SLDPRT 147.4 KB
S3DE_Zrightcantilever.SLDPRT 279.1 KB
S3DE_Zbottomsupport.SLDPRT 105.7 KB
S3DE_Left_top_strut.SLDPRT 119.8 KB
S3DE_Right_top_strut.SLDPRT 169.3 KB
DEFAULT-11.sldprt 66.8 KB
ecrou.SLDPRT 55.9 KB
rod.SLDPRT 48.7 KB
S3DE_Fanduct.SLDPRT 101.4 KB
S3DE_E3D_attachment_clamp.SLDPRT 75.6 KB
S3DE_Partcoolingfanmount.SLDPRT 133.4 KB
S3DE_E3D_attachment.SLDPRT 628.9 KB
S3DE_ExtruderHolder.SLDPRT 183.3 KB
e3d v6.SLDPRT 664.3 KB
Radial-Cooling-Fan-5015-DC12V.SLDPRT 338.6 KB
S3DE_LeftLCDSupport.SLDPRT 223.7 KB
S3DE_LCDBezel.SLDPRT 348 KB
S3DE_RightLCDSupport.SLDPRT 271.7 KB
RAMPS LCD2004.SLDPRT 112.7 KB
rod.SLDPRT 48.7 KB
DEFAULT-6.sldprt 89.3 KB
S3DE_Under_bed.SLDPRT 60.5 KB
S3DE_Bed.SLDPRT 53.4 KB
S3DE_ArduinoMegaTab.SLDPRT 71.5 KB
S3DE_CableHolder.SLDPRT 145 KB
MEGA_R2_MOUNT.STL 175.8 KB
S3DE_Zbottomsupport.STL 58.3 KB
S3DE_Zrightcantilever.STL 217 KB
S3DE_Ztopsupport.STL 89.5 KB
S3DE_Zleftcantilever.STL 215.1 KB
Belt guidance Y.stl 67.7 KB
Support pulley X.stl 361.8 KB
Z_motor_piece_1_2.stl 387.4 KB
Belt guidance X.stl 68.1 KB
Opposite linear guidance.stl 142.8 KB
Motor linear guidance.stl 160.7 KB
Z_motor_piece_2_2.stl 197 KB
Support pulley Y.stl 363.5 KB
Support motor Y.stl 118.3 KB
Z_top_connector.stl 187.2 KB
Bottom connector.stl 90.6 KB
Top connector.stl 171.2 KB
Support motor X.stl 120.4 KB
S3DE_E3D_attachment_clamp.STL 29.2 KB
S3DE_Fanduct.STL 11.2 KB
S3DE_ExtruderHolder.STL 217.2 KB
S3DE_E3D_attachment.STL 1.1 MB
S3DE_Partcoolingfanmount.STL 131.7 KB
S3DE_LeftLCDSupport.STL 265.2 KB
S3DE_RightLCDSupport.STL 251 KB
S3DE_LCDBezel.STL 782.5 KB
S3DE_CableHolder.STL 247.5 KB
S3DE_ArduinoMegaTab.STL 20.4 KB
MEGA_R2_MOUNT.STL 175.8 KB
