Openscad

Use the openscad file to create your own frame.

[https://github.com/fz72/openscad_frame](https://github.com/fz72/openscad_frame)

You can use these parameters:

length = 53.5;         // Length (X)
width = 10;            // Width (Y)
height = 10;           // Height (Z)

groove_height = 1;     // Groove height (Z)
groove_depth = 2;      // Groove depth (Y)
groove_pos_height = 4.5; // Groove position height

tenon_width = 4;       // Tenon width (Y)
tenon_height = 4;      // Tenon height (Z)
tenon_depth = 5;       // Tenon depth (X)
tenon_radius = 3;      // Tenon radius

corner_part = true;    // Add corner part (true = yes, false = no)
corner_length = 77;

add_holes = true;       // Enable/disable holes in the middle
hole_diameter = 3;      // Diameter of the hole
hole_depth = 5;        // Depth of the hole

Puzzle frame 682x482mm

Use the files in the separate folder. Please pay attention to the file description.
Print 4 cornors
Print 4 edges (199mm)
Print 2 edges (200mm)
