To use this model you need some additional hardware:

• 2x M5 10mm (or longer) Screws, to mount the printed plate to the original lighthouse mount.
• 1x M5 40mm (or longer) Screws, to connect the two pieces together.
• 3x M5 nuts

Assembly:

1. Screw the lighthouse mount on the"MountAdaptor" Plate with the two increases fitting into the back of the original mount. Note that it only fits in one direction not upside down. Use the two M5x10mm Screws to do that.
2. Slide the two parts together on the side that you want to use the angle on.
3. Insert the nut into the hexagonal cutout. To make it easier, you can put the nut on a screw and push it in, then remove the screw.
4. Take a M5x40mm (or longer) screw and push it through the other side and turn it through the nut but do not fasten completely yet.
5. Mount the assembled angle adaptor on the wall and set the angle, now fasten the screw to the end, so the angle can't change anymore.
6. Now mount the Lighthouse to the mount.
