Modelo 3D Sovol SV08 - Optimized Macro.cfg & printer.cfg / Orca G-Code & Settings (Github now) por kampfwuffi no Printables

Descrição

Github now: Sovol SV08 - Optimized G-Code / Macro.cfg / printer.cfg and highspeed settings PETG

Further releases and instructions on GITHUB:

[https://github.com/kampfwuffi/Sovol-SV08-Optimized-Macros](https://github.com/kampfwuffi/Sovol-SV08-Optimized-Macros)

HOW HARD IS IT TO IMPLEMENT?

Basically it's a work of 15 minutes.
Simply copy/paste the code from Macro.cfg and printer.cfg over your original cfgs. Additionally paste your serial numbers from old printer.cfg to new printer.cfg. Optimized Orca Slicer settings are optional EXCEPT Machine start G-Code and 0.6mm nozzle setting in Orca Slicer settings AND printer.cfg if 0.4mm nozzle installed!
Do STEP 1 TO STEP 5 for best experience.

ATTENTION:

  • See GITHUB page for implementation instructions!
  • Use at own risk, this is WORK IN PROGRESS.


Further releases and instructions see GITHUB:
[https://github.com/kampfwuffi/Sovol-SV08-Optimized-Macros](https://github.com/kampfwuffi/Sovol-SV08-Optimized-Macros)

============
OPTIONAL ORCA profile settings (higher speed, 0,6mm nozzle, PETG temps, tweaks for cleaner prints,…):

Speed & Filament Settings:
Attention: Higher speeds will add wear to the mechanics, this will lead to more repair/maintenance

Quality & Cooling Settings:

Disable all Z-hops in all settings pages! Much better prints, no stringing and no additional stress!

Strength & Extruder 1 Settings:

Do not use sparse infill patterns wich cross it's paths, it might fail your print!
Best is Rectlinear infill for Infill setting, fast prints and low stress. Cross Hatch pattern is more stress due to vibrations, but okay because no path crossing!

Others & Motion Ability Settings:

There is a Settings Override Tab in Orca: Set Retraction also to 0.6mm there or you will get small holes in your print surface from time to time!

Please give feedback and comment for more optimization.

Disclaimer:

This guide and all changes have been made with the best intentions but in the end, it's your responsibility and only your responsibility to apply those changes and modifications to your printer. Neither the author, contributors nor Sovol is responsible if things go bad, break, catch fire, or start WW3. You do this at your own risk!

Printables

Sovol SV08 - Optimized Macro.cfg & printer.cfg / Orca G-Code & Settings (Github now)

Publicado em 28 de nov de 2025

181
Curtidas
2,074
Downloads
4
Impressões
Categoria Other Printer Parts & Upgrades
Tags
orca klipper sovol config orcaslicer sovolsv08
Licença GNU General Public License v3.0
Arquivos (1)
SV08-feet riser cylinder for fan mod.stl 56.3 KB
