🆕 The “MagLink” Splicer

🌟 INTRODUCTION ~ ~ ~

*MagLink-Fitt ~ Uploaded to pair with a SUNLU S4 Dryer!

[ The “Fitt” allows users to insert one end into the Dryer allowing the MagLink-Quad to attach effortlessly ]

[ DOWNLOAD PROFILE ]

This model utilizes [4] 6x3mm magnets which allow you to [Connect aka “Link”] PTFE tubes resulting in Faster and Easier feeding from filament dryers!

📝🛠️ BILL OF MATERIALS ~ ~ ~

• [8] 6x3 mm Magnets LINK (US) - Avaliable from Maker's Supply! Both [5x3mm] & [*6x3mm]
• OR
• [8] 5x3 mm Magnets - LINK BELOW DIRECTLY TO Maker Supply
• [2] PC4-M10 / Male Threaded Pneumatic PTFE Fittings LINK (US)

✅ ASSEMBLY ~ ~ ~

1. Make sure to [Add pause] @ [Layer #24] / Z: 3.84mm
2. Grab your [6x3 mm] Magnets
3. @ Pause [set] Magnets into holes with correct polarity! [EZ way is having them stacked and placing face down same orientation]
4. Thread PC4-M10 Fittings with Ease
5. Push in [PTFE] Tubes
6. Enjoy seamless hassle free manual loading from a dryer!

📌 IMPORTANT ~ ~ ~

• Make sure to note [S] & [N] poles so they attract each other! Otherwise they won't “Link” together
• Do not over tighten fittings!
• HIGHLY ENCOURAGE [*6x3mm] Magnets for BEST CONNECTIONS!
• If you use shorter/smaller magnets; Linking strength between [MagLinks] will NOT be adequte enough!
• Test connection system before adding to setup
• Don't forget to add a manual [pause] if you're using the RAW FILES & not our print profile!
• Currently NOT RECOMMENDED for use between [AMS > AMS BUFFER > TOOLHEAD]  X1C & P1S Currently working on a permanent solution in the near future but as of now the risk of disconnection of [MagLink's] will cause [failure to Feed into Toolhead]

💬 BACKGROUND ~ ~ ~

The “MagLink” system is a versatile mechanism which will continue to bring future mods to the community, brought to you by us @Protospyre LLC. This mod is an innovation that makes life easier when using dryers or other setups that require lengths of tubing. We use this and made it specifically for our Sunlu S4 Filadryers! Use [MagLink-Fitt] (Released New Print Profile!) to connect outside your S4 Dryer! or Link-up to ANY Pneumatic Fitting with a 4mm I.D!!

📢 STATEMENT ~ ~ ~

Currently NOT existent on MakerWorld! Made for Makers by Makers

📝 CHANGELOG ~ ~ ~

[*] = Latest Update

• *07/12/24 ~ Updated Descriptions - Text Color identification
• 06/13/24 ~ Updated BOM: Now BOTH [6x3mm] & [5x3mm] Magnets avaliable on Maker Supply!
• 05/12/24 ~ Official Release Rev 1.0 - [MagLink-Fitt] / Tailored for Sunlu S4 Filadryers /or ANY Pneumatic Fitting!
• 05/04/24 ~ Official Release Rev 1.0 - [MagLink-Quad]

🎉 MENTIONS ~ ~ ~

Modeled in Fusion by Autodesk

📬📊

Please leave a 👍 or 👎 / Rating and how this worked for you or didn't! This helps us address the areas of improvement

If you have an idea of what could use the [MagLink] system please share it with us!

[NEW] -  BOOOOOSSSTT! - You get points also!

THANK YOU!

HAPPY PRINTING!
