🕐 Personalized Name Clock
Turn any name into a working wall clock! This is a fully parametric model — customize it right in your browser: type a name, pick a font, add an icon, and it builds a clean two-color clock dial ready for a standard quartz movement.
✨ Features
• 🔤 Any name — bubble-border, raised-letter style.
• 🎨 Full font picker — any font and style you like.
• 💠 Optional icon — flows inline like an extra letter, sharing the same border.
• 🧵 Two-color ready — separate color regions for plate and letters (AMS or single color).
• ⚙️ Shaft hole + flat mounting pad — sized for a standard quartz movement; the pad keeps it clamped square.
• 🕰️ Optional printable hands — hour, minute and second, printed flat alongside the dial.
• 📏 Fully scalable — one parameter resizes the whole clock.
🎯 Icons to choose from
❤️ Heart
💎 Diamond
🌸 Flower
🌺 Flower2
🦋 Butterfly
👑 Crown
🚗 Porsche
⚽ Soccer
⭐ Star
🛠️ What you need to finish it
• 🔋 A standard battery-powered quartz clock movement, with its washer and nut.
• 🕐 Clock hands — the printable set included here, or the metal hands from your movement kit.
• 📐 The center hole defaults to 8 mm — measure your movement's shaft and adjust in the customizer if needed.
🖨️ Printing
• Print the dial flat, letters facing up — no supports needed.
• For two colors, assign one filament to the plate and one to the letters/icon.
• If you enable the hands, they print flat next to the dial.
🔧 Assembly
• Print the dial (and hands, if enabled).
• From the back, push the movement shaft through the center hole.
• Secure the movement with the washer and nut on the front.
• Fit the hands: hour, then minute, then second.
• Insert a battery, set the time, and hang it! 🎉
🎛️ Customizer parameters
• Name text and font
• Overall size, plate thickness, letter height
• Icon, icon position (start/end), icon size and spacing
• Center hole diameter and mounting-pad size
• Optional printable hands and their hole sizes
