Honeycomb Adjustable Phone Stand (No Supports!)

A functional, stable, and highly adjustable smartphone stand designed with a beautiful aesthetic honeycomb backplate and robust mechanical locking joints. Print-ready in 2–3 hours with zero supports (except for a tiny organic support on the phone plate "ear").

⚙️ Key Engineering Features

• Interlocking Teeth Locking System: Uses robust 3D-printed gears built directly into the pivot joints. When you tighten the knobs, the teeth mesh to physically lock the angle—preventing slipping or sagging over time!
• Engineered Stability: Designed with a wide, flat footprint base and structured arms featuring internal triangular trusses to maximize strength while saving filament.
• Fast & Easy Print: Entire model prints in just 2 to 3 hours.

🛠️ Assembly Guide (Important!)

Note on the Arms: The two structural arms are visually identical but functionally different. One has internal threads, and the other does not. Look for the "1" and "2" numbers engraved on the inside of the arms to easily distinguish them.

1. Place Arm 1 and Arm 2 into the base channels. Ensure the arm with the internal thread is aligned with the side where the screw enters.
2. Insert all 3D-printed screw knobs through the joint axes. Do not tighten them completely yet (keep them loose to easily adjust the angle first).
3. Bottom Double-Knob: The bottom axis has two adjacent wheels. One is the structural locking screw; the other is a decorative matching nut. Simply thread the decorative nut onto the protruding screw end.

📱 How to Use

1. Loosen First: Always loosen the printed knobs slightly before changing the angle. Rotating the stand while locked will wear down the plastic teeth!
2. Set Angle: Rotate the arms and phone holder plate to your desired position.
3. Tighten & Lock: Firmly hand-tighten the knobs until the gear teeth fully mesh and lock (do not over-tighten).
4. Mount Mobile: Place your smartphone on the stand only after verifying all joints are safely locked.
