A simple, robust, and functional print-in-place hinge. Designed to be printed completely assembled with no additional hardware required. It folds smoothly up to 180 degrees right off the build plate.

Engineered with a precise 0.25mm clearance, making it perfectly optimized for FDM printing. Tested and prints flawlessly on the Bambu Lab A1.

Features:

• Print-in-Place: No assembly or screws needed.
• Optimized Clearance: 0.25mm gap guarantees a smooth rotation without the parts fusing together.
• Support-Free: Designed to print flat on the bed without any support structures.

Recommended Print Settings:

• Supports: No
• Infill: 15-20% (Gyroid recommended)
• Wall Generator: Classic or Arachne
• Wall Ordering: Outer/Inner (Crucial for accurate hole dimensions and maintaining the clearance)
• Seam Position: Aligned / Back (Ensure the Z-seam does not fall inside the hinge gap to prevent binding)
