Hexagonal Lithophane lampshade for E27 base

this lampshade is made with makerlab´s make my lithophane
and it fit´s normal European E27 base

instructions

Print 6  Bracket for Lampshades
print 6 Frame for Lampshade
print 6 corner pieces
print 1 Tightening sleeve

use 6 different photos and use Makerlab,s Make my lithophane function
use Mono Litho without frame
use 1:1 ratio and width and Height 180mm
change attribute Margin to 2,5 mm
then finishet lithophane should be 185mm x 185mm
i used thickness of 3.2 mm

then lithophane need to glued to the frame
assemble the lampshade with corner pieces

build bracket and push sleeve so it stay together

install lampshade to E27 base
It was a little tight so I had to rotate it into place.

Bracket and corner piece was printed dark grey

Frame and lithophanes was printed at white
