Descrição
Tired of treble hooks snagging your guides, line, clothes, car/truck seat, or fingers? The Hook Guardian Pro keeps your hooks exactly where they belong! This easy-to-mount fishing rod accessory provides a secure parking spot for treble hooks, single hooks, and many lure styles while you're moving between spots, transporting rods, or storing your gear.
Designed to help reduce tangles and protect your rod, this compact holder gives anglers a clean, organized way to secure their tackle in seconds. The durable design mounts directly to your rod and keeps hooks locked down and ready for the next cast.
Whether you're chasing bass, walleye, pike, crappie, or panfish, this hook keeper helps keep your setup neat, safe, and ready for action.
🎣 Secure your hooks. Protect your gear. Spend less time untangling and more time fishing!
Parts Needed
- 4 × M3x10 Bolts
- 4 × M3 Nuts
- Your preferred glue or adhesive
Assembly Instructions
- Select the insert size that matches your fishing rod diameter.
- Sizes included: 8mm, 10mm, 12mm, and 14mm.
- You can download each size individually or download the complete file and print only the sizes you need.
- Position the hook holder on your rod. I recommend mounting it on the top side of the rod so it stays out of the way while casting.
- Apply a small amount of glue into the center slots of the main body.
- Insert the piece with the "V" shape into the glued slots first.
- Place the top and bottom halves around your fishing rod.
- Insert the four M3x10 bolts through the mounting holes and install the M3 nuts on the opposite side.
- Tighten the bolts gradually in a crisscross pattern, applying even pressure around the holder as you go.
Notes
- The bolt holes are designed to be slightly loose in the top section and snug in the bottom section to make assembly easier.
- A small gap between the top and bottom pieces is intentional. This allows the holder to clamp securely onto the fishing rod as the bolts are tightened.
- Do not overtighten. Tighten only until the holder is firmly secured and does not rotate on the rod.
