Design Concept This flush-mounted power box is designed for convenient installation inside walls, keeping outlets seamlessly integrated and out of view. Its sleek design ensures compatibility with standard power sockets while maintaining structural stability. Purpose Ideal for residential and commercial buildings where aesthetics are important, this model allows for hidden installations of multiple power outlets, enhancing the visual appeal of any room. Printing Suggestions Use high-strength filament such as PETG or ABS for durability. A layer height of 0.2mm is recommended for fine details and a sturdy construction. Assembly Instructions Ensure the dimensions are compatible with existing wall cut-outs. Use appropriate screws for mounting, ensuring they do not penetrate essential components.

• spacing of screws securing a single device: 60mm
• spacing of devices: 70mm
• screw size: fi 3mm x L 15-25mm
• diameter of the hole needed: 66-68mm

• Can size:
   - Single can: 66mm
   - Double can: 136mm
   - Triple can: 206mm
   - Quadruple can: 276mm
   - Five-fold can: 346mm


• ----------------------------------------


  ⚠️ SAFETY & LEGAL DISCLAIMER

  Due to varying electrical regulations and safety standards across different countries, this model must be printed using flame-retardant or self-extinguishing filaments (commonly designated by manufacturers as V0, FR, Flame Retardant, etc.).



  By downloading and using this model, you acknowledge that you do so at your own risk. The author accepts no responsibility or liability for local regulatory compliance, the choice of printing materials, or any damages, accidents, or legal issues resulting from the improper use, printing, or installation of this model. Always consult a qualified electrician for electrical installations.
