HomeRacker-Compatible Configurable Rod Generator

A clean parametric rod generator for HomeRacker-compatible builds.

In addition to standard solid and hole connector faces, this generator adds unique Tooth and Divot connector options designed to work with HomeRacker-style connectors.

This makes it possible to generate rods with more connector behavior than a simple solid/hole setup, while still fitting into HomeRacker-compatible builds.

What This Makes

This file creates straight HomeRacker-compatible rods with independently selectable connector patterns for:

• End units
• Middle units

Connector face types include:

• Hole
• Divot
• Tooth
• Solid

The end units and middle units can use different connector patterns, making it easy to create rods with specialized ends and a different main body pattern.

Features

• Parametric rod length
• Separate end-unit and middle-unit connector patterns
• Solid, hole, Divot, and Tooth connector face options
• Generated rod geometry
• Built-in tooth geometry for grabbing the connectors before inserting a pin
• Optional rod type label
• Optional connector-code label

Compatibility Note

This model is designed for HomeRacker-compatible builds.

It is not an official HomeRacker model. It is an independently developed compatible rod generator with custom connector generation and custom cutter implementation.

Recommended Use

Use this generator when you want simple connector rods for building, spacing, testing layouts, or expanding a HomeRacker-compatible setup.

Customizer Options

Main options include:

• Rod unit count
• End unit connector pattern
• Middle unit connector pattern
• Rod label on/off
• Connector-code label on/off

Notes

This file is intentionally kept simple so it can serve as a clean standard rod generator for HomeRacker-compatible builds.
