Roller Extender – Smooth Pattern Edge

A extender to texture roller with a 13mm center hole, 3.8 cm diameter roller. The test files are included so you can check that the extender fits correctly inside your roller before using the full setup.

The extender is designed to help stop a sharp edge line forming in the rolled-out pattern when using a texture roller. It supports the roller edge more smoothly, helping the texture roll clean across clay, pottery, ceramics, polymer clay, and craft surfaces.

Profiles

✅ Test files - for 12.8mm and 12.6mm version
✅ 12.80mm Rod. 0.20 mm clearance option, Plus extender Ends
✅ 12.60mm Rod, 0.40 mm clearance option, Plus extender Ends

Included Parts

✅ Roller extender pieces - short and long

✅ Rods
✅ Test rod pieces
✅ Test screw


Use

Use the test file first to check that the extender fits inside your texture roller. Once you know which clearance fits best, use the extender to help reduce sharp edge marks in your rolled-out clay pattern.

Clearance Guide

✅ 0.20 mm clearance [12.8mm]: tighter fit
✅ 0.40 mm clearance [12.6mm]: easier/looser fit

Why Use It?

✅ Helps stop sharp edge lines forming in rolled-out patterns
✅ Helps the roller edge move more smoothly
✅ Designed for texture roller setups

Tested Print Settings

Layer height: 0.08 mm - a must so thread prints correctly
Infill: 15% Crosshatch
Perimeters/Walls: 2
Raft: Not required
Supports: None
