Cardputer Wallmount for M5Stack Cardputer & ADV

🏷️ TITLE

Cardputer Magnetic Wallmount – Dual Design (M3 Hex + Standard Screw) for M5Stack Cardputer & ADV

🧲 DESCRIPTION

This magnetic wallmount is a clean, fast-access docking system for the M5Stack Cardputer and Cardputer ADV.
Designed as a dual-variant engineering system, it combines flexibility, stability, and a minimal workspace footprint.

The device snaps into place using an integrated neodymium magnetic system – fast, secure, and tool-free.

Dual Design System

This model is intentionally designed as a dual-variant system, not just two alternative versions.

It includes two integrated mounting options within the same design:

🧩 M3 Hex Screw Mount (Industrial Fixation)
🔧 Standard Screw Mount (Universal Fixation)

Both versions share the same geometry and fit system but are optimized for different real-world mounting scenarios.

Mounting System

The wallmount is fixed using an M3 hex head machine screw, providing a strong, stable and clean industrial installation.

A second version is included for users who prefer standard screw heads.

Magnetic System

The Cardputer is held securely using a flexible neodymium magnet system:

2× 8×4 mm round magnets
OR
4× 8×2 mm magnets (stacked to 4 mm height)

Both options fit into the same slots.

Print Settings

No supports required
25% infill is sufficient
PLA or PETG recommended
Fully optimized for FDM printing

Use Cases

Smart home control panel
IoT dashboard station
Workshop control unit
ESP32 / maker project hub
Desk or wall-mounted interface

Design Philosophy

A device like the Cardputer should not live in a drawer – it should live in the space where it is used.

Fast access. Clean placement. No clutter.
